Heater Module Diesel/Oil-Heated HHM Series HHM-3506-0E10

HHM-3506-0E10

Convert your cold water pressure washer into a hot water unit whenever the need arises with a heater module.  Each features a powder coated steel frame assembly and several fuel burner types are available.

Frame: Powder coated steel frame assembly · Stainless-steel coil wrap · 13-inch flat-free tires

Components: No. 1 or No. 2 fuel oil, diesel or kerosene fired burner (Not approved for bio-fuel) · Horizontal schedule 80 pipe coil heat exchanger · 35-foot power cord with GFCI · Adjustable thermostat

Miscellaneous: 250°F maximum outlet temperature (150°F temperature rise at 4.0-GPM)

Unit Includes: 12-foot x 3/8-inch jumper hose with quick connects to hook up to existing pressure washer

Specifications

PSI 3500
GPM 6.0
Electrical Voltage/Phase/Amp 115V, 1Ø, 3.2A
Burner Fuel Consumption 2.76 gph
Diesel BTU Per Hour 386,400
Mobility Portable Pressure Washers
Water Temperature Hot Water Pressure Washers

Weights & Dimensions

Net Weight 423.00 lbs.
Shipping Weight 543.00 lbs.
Length 56.50 in.
Width 30.00 in.
Height 41.50 in.

Skid Feet HX-0171

Stationary applications
