| Weight | 745 lbs |
|---|---|
| Dimensions | 53.5 × 28.75 × 42 in |
| Grade | Industrial |
| Water Temperature | Hot Water |
| Drive Type | Belt Drive |
| PSI | 3000 |
| GPM | 3.9 |
| Horsepower/Engine | 9.1 HP Kohler KD440 OHV |
| Pump | General |
| Engine Fuel Tank Capacity | 1.3 gallons |
| Burner Fuel Tank Capacity | 10.0 gallons |
| Burner Fuel Consumption | 2.76 gph |
| BTU Per Hour | 386,400 |
| Power Type | Diesel |
| Width | 28.75 |
|---|---|
| Height | 42 |
| Length | 53.5 |
| Shipping Weight | 745 |
| Net Weight | 626 |
Built with a powder coated steel frame, this series holds up on even the most demanding jobsites. It’s ideal for cleaning heavy equipment and large surfaces.
Pump:
·Factory preset unloader
·Low pressure detergent injector
Engine:
·Performance-proven Kohler diesel engine with electric start – battery not included
Frame:
·Powder coated steel square tube skid frame
·Stainless-steel removable front panel
·Optional wheel kit with locking tire brake, four tires and solid steel threaded axles
Components:
·12V Beckett burner – no need for a generator – battery not included
·Stainless-steel coil wrap heat exchanger with horizontal schedule 80 pipe coil
·No. 1 or No. 2 diesel or kerosene fired burner (Not approved for bio-fuel)
·Adjustable thermostat
Miscellaneous:
·Temperature rise 150°F/66°C above ambient, maximum outlet temperature is 200°F
Unit Includes:
·Quick connect nozzles – 0°, 15°, 25° and 40°
·50-foot x 3/8-inch high pressure hose
·Adjustable pressure insulated dual lance
·Professional-grade insulated trigger gun with safety lock-off
Limited Warranty:
·3 year engine
Certification:
·CSA Certified – US and Canada
